Product Details:
Place of Origin: made in china
Brand Name: royal
Certification: ISO
Model Number: RTAF-GB0101
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: BOX
Delivery Time: 5~8 weeks
Payment Terms: L/C, T/T
Supply Ability: 30 sets / month
Contact Now

70dB Robotic Grinder Automatic Brushing MachineHybrid Grinding And Brushing Equipment

Description
Working Stations: 1 Robot Grinder + 1 Automatic Brushing Station Operation & Control: PLC Controlled, Teach Pendant And Program Pages
Security: Dust-proof House Is For Option, Smoke Detector Is Designed Polishing Wheels: Automatically Compensations Design
Working Power: AC380/220V, 50/60Hz After-sales Service: Onsite And Online
Noise: Standard Noise: Less Than 70dB Applications: Sanitaryware, Kitchenware, Door Handles, Faucets Etc.
Drive: Siemens Servo Motor
Highlight:

70dB Automatic Brushing Machine

,

60Hz Automatic Brushing Machine

,

70dB Hybrid Grinding And Brushing Equipment


RTAF-GB0101-Hybrid Grinding And Brushing Equipment- 1 Robotic Grinder + 1 Automatic Brushing Unit





This system is designed with 1 robotic cell of sand grinder and 1 unit of automatic brushing unit, which can makes the finished brushing surface treatment for Nickel electroplated products. The robot grinder is designed with a full-floating control module making it more flexible for all sides of grinding.



Technical Specifications



1 robot: 1 grinder + 1 automatic brushing unit ( hairline drawing)
Model RTAF-GB0101
Machine Layout L*W*H (mm) 3200*2800*2300
Total N.W. 2000kgs
Robot Model Fanuc M-20iD/25kg
Qty. Of Robot 1 set
Dust-Proof House None, available
Sand Grinding Units 1 ( 2 stations)
Automatic Brushing (Hairline drawing) Unit 1 set
Loading/Unloading Table 1 set( double-station )
Total Power Consumption Max. 12 KW














Main Features



1. Automatic tension adjustment for sand grinding belt



2. Automatic deviation correction and adjustment for sand grinding belt



3. Automatic wax injection for the fine polishing procedure



4. Automatic compensation for rotary motor speed



5. Multi-stages rotary speed programming



6. Full range of buffering/floating for contact wheels



7. Loading/unloading detection performance



8. The automatic brushing station is designed with an auto-compensation function for brushing wheels


9. Applied to small-size products sand grinding, and brushing processes until electroplating post-treatment






















Operation and Control System


Teach Pendant and Program Pages

1. Easy Operation

2. Easy Writing and Modify Program
3. Designed with an  EMERGENCY EMERGENCY STOP BUTTON u


Design Advantages


Flexible,
Stable quality,
High productivity,
Less production cost,
Safer



Layout - Key configurations





70dB Robotic Grinder Automatic Brushing MachineHybrid Grinding And Brushing Equipment 0



70dB Robotic Grinder Automatic Brushing MachineHybrid Grinding And Brushing Equipment 1



We provide you not only the grinding and brushing equipment but know how to transfer the technology, professional training, and technical support for machine operation, and program writing. Please contact us today for a FREE consult.
